        The new 5i Series


            |
                57i
                CT
                Download
                a Brochure

                Full featured large screen LCD phone with backlit display and
                built in DECT
                cordless phone
                Handles up to 9 calls simultaneously
              All the features of
                the 57i phone with full DECT cordless capability.

                - Cordless
                  uses 2.4 GHz Frequency Hopped Spread Spectrum

                - Cordless
                  has 4 day standby, 4 hour talktime.

                - Add up
                  to 3 more Cordless handsets






             |


                 57i
                  Download a Brochure

                   Full featured phone with 144x128
                  Pixel backlit Graphical LCD Display. Handles up to 9 calls simultaneously


                    -  4
                      programmable keys with LEDs

                    - 4 navigational keys

                    - 12
                      customizable softkeys with LEDs, programmable up to 30 functions


                    - Supports
                      up to 3 M536 or M560 Expansion Modules

                    -  Multi-Proxy
                      Support

                    - Distinctive
                      Ringing and Priority Alerting

                    - Embedded
                      XML Browser

                    - 144x128
                      Pixel Graphical LCD Display

                    - Soft
                      White Backlighting Configurable for Always On, Always off
                      or Auto

                    - Full
                      Duplex Speakerphone





             |

                55i
                Download
                a Brochure
                Exceptional Features and Value in an Advanced Featured,
                Expandable IP Telephone. Handles up to 9 calls simultaneously

                -  4 programmable
                  keys with LEDs

                - 4 navigational keys

                - 6 customizable
                  softkeys with LEDs, programmable up to 20 functions


                - Supports
                  up to 3 M536 or M560 Expansion Modules

                -  Multi-Proxy
                  Support

                - Distinctive
                  Ringing and Priority Alerting

                - Embedded
                  XML Browser

                - 144x75
                  Pixel Graphical LCD Display

                - Soft White
                  Backlighting Configurable for Always On, Always off or Auto

                - Full Duplex
                  Speakerphone


             |


             53i

              Download
              a Brochure

              The 53i from Aastra offers powerful features and flexibility in
              a standards based basic level IP telephone.
              This phone handles up to 9 calls simultaneously.


                -  6 call
                  appearance lines with LEDs

                - 4 navigational keys

                - 3 programmable
                  keys with LEDs

                - 3 Line
                  X 16 Character LCD Display

                - Supports
                  up to 3 M536 or M560 Expansion Modules

                -  Multi-Proxy
                  Support

                - Distinctive
                  Ringing and Priority Alerting

                - Embedded
                  XML Browser


                - Full Duplex
                  Speakerphone


             |

                536M
                module
                Download a Brochure

                36 keys with LED’s



                 560M
                LCD module
                Download
                a Brochure

                20 softkeys with LED’s. 3 hardkeys with LED’s access three screens,
                offering up to 60 available keys.


             |

                51i

                Download a Brochure

                Entry level single line set with
                3 line/16 character display
                9 configurable speed dial keys using the number keypad

                -  1 call
                  appearance key

                - Swap key

                - 4 navigational keys

                - 9 programmable
                  speed dial keys using the numerical keypad

                - 3 Line
                  X 16 Character LCD Display

                -  Multi-Proxy
                  Support

                - Distinctive
                  Ringing and Priority Alerting

                - Embedded
                  XML Browser


                - Full Duplex
                  Speakerphone





             |



        Aastra SIP Phones


            |

                480i CT with Cordless DECT

             |


                480i Large screen

             |


                9480i CT with cordless DECT
             |

              9480i Large screen IP |





     |


        Award Winning
        SIP-DECT Cordless phones

        Aastra SIP-DECT™ has ben singled out for Innovation and Quality


        Download
        a Brochure
        This scalable, enterprisegrade, mobility solution allows users to take
        the features and voice quality of their desk telephone with them throughout
        their office environment or related branch offices serviced by the same
        Corporate network.
      DECT technology
        virtually eliminates issues of dropped calls, interference, security and
        range by employing IP DECT access points that seamlessly “handoff” calls
        and enable roaming.
       This system is
        ideal for any single or multi-location business, retail or institutional
        setting that requires mobile employees to be available to take or receive
        calls at any time.

        Features



        - Seamless Mobility DECT technology offers reliable, high quality, secure
          voice access throughout a building or across a Corporate network with
          full roaming support.

        - Handsets act as normal company extensions, allowing staff to be reached
          in both headquarters and branch office locations.

        - Employing advanced authentication/encryption technology, DECT is constantly
          monitoring transmissions and will automatically adjust channels to avoid
          possible interference.


          Feature Rich Handsets

          The SIP-DECT 142 handset is a powerful tool for business communication
          on the go.

          Featuring a 5-line illuminated display with two softkeys for feature
          access, illuminated keypad, a variety of informational status displays,SOS
          key for an emergency speed dial number, caller/directory and redial
          lists, the handset also offers hands free operation, built in speaker
          and headset jack.

          Scalability The Aastra SIP-DECT system, using DECT 142 handsets and
          RFP 32 IP DECT access points, can grow as your business expands. By
          simply adding additional handsets and access points, the Aastra SIP-DECT
          solution can easily expand to meet changing business requirements.

          Up to 512 handsets can be deployed using up to 256 IP access points.
          *

          Simple Deployment Aastra’s SIP-DECT solution can be easily deployed
          in most open-standard IP environments including; Hosted or Premised
          based using a SIP based IP-PBX, Hybrid PBX or Open Source PBX. The solution
          requires limited engineering planning and is managed by OpenMobility
          ManagerTM (OMM) software and provisioned on the SIP based infrastructure
          as simple SIP Extensions. The OMM can be installed on the DECT access
          points, a PBX or a Linux server.




     |
